A molar tooth brainstem with a bat-wing fourth ventricle: Joubert syndrome

Muhammad Awais, Yousuf Husen, Abdul Rehman


A 28-month-old boy was brought by his parents for evaluation of poor growth. Parents reported that the child started neck-holding and sitting at 14 and 24 months of age respectively. He was also unable to walk. His speech was limited to ‘mama’ and ‘dada’ only. Examination showed generalized hypotonia and strabismus. Mother reported that one of the child’s maternal cousins has had similar symptoms. Magnetic resonance imaging (MRI) of the brain was obtained, which showed a molar tooth configuration of the brainstem, bat-wing appearance of the fourth ventricle, absent inferior cerebellar vermis and horizontally placed cerebral peduncles. These radiographic appearances were consistent with a diagnosis of Joubert syndrome. This disease is a rare inherited ciliopathy characterized by typical malformations of the brainstem. Based on genetic analysis, Joubert syndrome is now recognized as a group of several related genetic disorders, which manifest phenotypically in a similar manner. The most common genetic defect implicated in this disorder is a mutation in the gene ARL13B encoding for adenosine diphosphate ribosylation factor like GTPase 13B. Patients usually present early in life with developmental delay and cerebellar ataxia. Most patients have associated abnormal eye movements (usually jerk nystagmus) and an abnormal pattern of breathing (episodic apnoea and tachypnea). Prognosis of such patients is dependent upon the presence of associated abnormalities. About 50% of children eventually learn to walk independently with an ataxic gait.

Keywords: Joubert syndrome; ciliopathy

Full Text:



Romani M, Micalizzi A, Valente EM. Joubert syndrome: congenital cerebellar ataxia with the molar tooth. Lancet Neurol 2013;12(9):894–905.

Cantagrel V, Silhavy JL, Bielas SL, Swistun D, Marsh SE, Bertrand JY, et al. Mutations in the cilia gene ARL13B lead to the classical form of Joubert syndrome. Am J Hum Genet 2008;83(2):170–9.

Saleem SN, Zaki MS. Role of MR imaging in prenatal diagnosis of pregnancies at risk for Joubert syndrome and related cerebellar disorders. AJNR Am J Neuroradiol 2010;31(3):424–9.
